ESD workspaces PRODUCT CATALOGUE 2025
Improved user experience with our enhanced 3D Configurator! The latest version boasts a suite of enhancements, ensuring a more intuitive, user-friendly, and visually appealing experience. To get started, all you need is a mobile phone or a computer with internet browser; no downloading is required and using the software is free of charge. Design your own workstation or trolley and view it in 3D 3d.treston.com ONLINE 3D CONFIGURATOR
Workbench accessories ESD accessories for Concept Ergo, QuatreX, TED, Quick Edge and TP 29 ESD accessories for WB and QuatreX 42 ESD accessories for TPH 45 Other ESD accessories 48 Non ESD sertified accessories 49 Lighting 53 Spare parts 84 Chairs 57 Workbenches Concept Ergo - the most versatile workbench 14 WB - aesthetic and easily adaptable 18 QuatreX - 4-legged electric workbench 20 TED - electric desk for industrial use 22 TP - ideal basic workbench 24 TPH - standard workbench with one shelf 26 Quick Edge - extremely fast height adjustment 28 ESD protection in technical and industrial workplaces 4 Drawer units Drawer units 30 and 35 70 Drawer unit 45 72 Storage systems FiFo Flow Rack 75 Shelving system 77 Industrial cabinets 77 Shelving cabinets 78 Small-parts storage cabinets 79 Spacemisers for small-parts storage cabinets 80 Storage bin cabinets 81 Spacemisers for storage bin cabinets 81 High density storage cabinets 82 ESD bins 83 Trolleys Universal trolley WTR 60 Treston Industrial Multi trolley 61 Adjustable trolley TRTA 64 Reel holder trolley RRT 65 Mobile workstations 66 Trolleys for additional workspace 67 Bin and cabinet trolley 68 Tool trolley 69 Workspaces for happier workfaces
4 TRESTON | ESD WORKSPACES There’s no way around it. Sustainable long term business success in every industry is founded on empowered, motivated and healthy employees, and hyper adaptability to constant change. The solution is simple. A smart industrial workspace that adapts flexibly to the needs of the individual and the constant changes in the process. A next generation workstation and material flow solution that drives better business performance , environmental performance and personal performance by integrating and optimizing all work phases into a leaner, cleaner and greener process. WORKSPACES FOR HAPPIER WORKFACES With decades of experience, in depth understanding of ergonomics in industrial environments, unmatched ESD competence and proven LEAN knowhow we at Treston are in a unique position to help our customers in keeping their business and people in good shape. Workspaces for happier workfaces. This is our aspiration. This is our promise. This is what Treston is all about.
ESD Proof by Design™ 5 TRESTON | ESD WORKSPACES Work smarter, not harder Compliant and certified Safe, reliable, proven Versatile products and services Manufacturing or handling electronic components and products requires protection from ESD, electrostatic discharges. Even the smallest ESD can cause major damage to sensitive components, weaken the end-product's durability, or change its functionality. Costly ESD damages can be avoided by building an ESD protected area (EPA) where ESD workstations play a crucial role. At Treston, ESD protection is built into the very foundation of our ESD workstation solutions. All our high-quality and ergonomic workstation furniture is available as ESD-protected versions. For over 40 years, Treston has been the benchmark in ESD furniture because we create workspaces where safety, comfort, and performance go hand in hand. Treston's ESD workstation solutions are ESD Proof by Design™. • Compliant with international ESD standards, IEC 61340-51, IEC61340-6-1, and ANSI S20.20. • You can focus on performance, not compliance worries. • Treston has been the benchmark for ESD workstations for over 40 years. • Innovative conductive ESD paint reduces the need for separate grounding, creating cleaner, safer and more efficient workspace. • Our high-quality products have a 10-year warranty. • Comprehensive ESD product range with over 300 workstation accessories • Modular solutions - designed to adapt, scale, and grow with your needs. • Holistic ESD knowledge and extensive global customer support helping from consulting and planning to after-sales support
TRESTON | ESD WORKSPACES Watch this video: ESD workstation management Terms and explanations ESD Electrostatic discharge. Occurs when two electrically-charged objects come together and a charge is discharged. Could result in either immediate or latent damage to an electrical component ESDS Electrostatic discharge sensitive. A component that needs ESD protection. EPA ESD-protected area. Conductive material Conductor = material that permits electricity flow. Metals are often conductive, e.g. copper and aluminium. Insulating material Insulator = material that does not conduct electricity. The insulator can be electrostatically charged. Insulators can be plastic or wood, for example. Standards IEC 61340-5-1: ESD standard widely used in Europe and ANSI S20.20 in the Americas. Both standards have a great number of similarities. In ordinary movement a person creates static electricity. In these circumstances hand contact with a conductive material will discharge static from the body very rapidly. This is ESD = Electrostatic discharge. Static electricity has become a major problem in the electronics industry. Usually this passes unnoticed because our bodies do not feel discharges below 3000 volts. We may see ESD above 5000 volts as a spark. The most sensitive components may be damaged by a charge of just 30 volts, and many standard components ESD - Electrostatic discharge CHARGES GENERATED ON DAILY WORK ACTIVITIES Walking across a carpet 1 500 – 35 000 volts Walking over vinyl floor 250 – 12 000 volts Working at a bench 700 – 6 000 volts Picking up a plastic bag from bench 1 200 – 20 000 volts Chair with polyurethane foam 400 - 3 000 volts are sensitive to charges of 100...200 volts. The presence of inherent ESD is not easy to detect. Product-related defects can often be latent and become active over time. An unbroken ESD safety chain is essential to guarantee the quality of the final product. An ESD-protected production chain is called an EPA (= ESD Protected Area). Employees must be able to implement the right policies in an ESDprotected work environment. The lower the relative humidity the higher the voltage. The lowest values in the table usually apply when the relative humidity is 65-90%. During a cold winter day, the relative humidity in indoor spaces can be as low as 10 %.
1 2 3 4 5 6 7 8 9 7 TRESTON | ESD WORKSPACES Example of an ESD-protected area (EPA) Investing in an EPA is important 1. Common point ground 2. ESD floor 3. Semi-conductive table There are two types of ESD damage in industrial and technical environments. Firstly, a fatal defect that is usually easily detected during assembly or handling, or at least through careful testing. Such products are usually not delivered to customers. Secondly, another type of ESD damage is latent damage. This is difficult to detect with 4. Wrist strap + earth bounding point 5. Chair with ESD castors 6. Semi-conductive ESD shelf 7. Trolley with ESD castors 8. ESD garments (e.g. jacket and shoes) 9. EPA sign Static charge management of a working area: • ESD-protected workstations. Attention paid to ESD safe storing, moving and packing. • Personnel protected with shoes, wrist straps and other needed accessories • Staff training, work instructions and quality control • Cleanliness of ESD-protected equipment. Dust and dirt insulate. • Commitment to continuous improvement in static electricity management bear eyes and the product may pass all tests and function normally for some time. However, latent damage affects the performance and durability of the product and and often results in poor product quality.
8 TRESTON | ESD WORKSPACES Semi-conductive laminate level • Grounding resistance 106 – 108 Ω • Surface resistance 106 – 109 Ω • Withstands the heat of the soldering iron, most acids and bases Semi-conductive painted steel parts • Surface resistance 105 – 109 Ω Semi-conductive Polypropylene = PP • Surface resistance 103 – 106 Ω • Throughput 103 – 106 Ω / • Temperature resistance from -20° / + 70° C Semi-conductive polystyrene = PS • Surface resistance 103 – 106 Ω • Throughput 103 – 106 Ω • Temperature resistance from -40° / + 55° C ESD materials 6-Point checklist for creating and maintaining an EPA 1 CONTROL PLAN Includes e.g. component/product sensitivity levels, ESD protection level, daily routines and maintenance procedures. 2 FLOORING Grounded ESD floor or mat enables convenient usage of trolleys and chairs in EPA. 3 FURNITURE All furniture in EPA needs to be grounded. 4 PERSONNEL Wrist strap is the most efficient way to ground people working on EPA. 5 STORING, MOVING AND PACKING Store ESDS components in their original packages and minimise the transportation and movements. 6 CLEANING AND TESTING Regular cleaning with ESD detergent in EPA maintains the ESD protection.
9 TRESTON | ESD WORKSPACES The ESD control plan determines how valuable and sensitive components and parts are protected from ESD damage, to set their own ESD limits, if necessary, and to establish a testing schedule for ESD materials. The ESD monitoring plan is the starting point for static electricity management and is one of the issues defined by IEC 61340-5-1. The ESD Standard provides certain thresholds, and with your control plan you can set the level you want above or below the standard, depending on how sensitive your components are and what your needs are. The ESD control plan will usually also include information about the selected grounding system and method. The control plan shall also describe ESD products such as desks and trolleys, as well as maintenance, servicing and cleaning measures. An ESD control plan is a written plan of how components are handled during storage, transfer and packaging. Also note that employees must be well trained and informed about the ESD control plan and how it is implemented at your workplace. Everyone needs to know why the plan has been made, what it contains and how the ESD Protected Area (EPA) should work. Everyone needs to understand the importance of static electricity management and its implications for product quality, cost, and, ultimately, customer satisfaction. It is a good idea to make the ESD control plan part of your company's quality system so that everyone in your company understands its importance. The ESD control plan Setting up an ESD environment is simple and straightforward. An ESD-protected area can be small, for example, one workbench, or it can be large, with hundreds of workbenches. However, both areas need the same procedures, only the scale is different. Everything starts with the ESD control plan. Then you just need to roll up your sleeves and start implementing the plan, beginning with the floor and the common point ground, moving to ergonomic and ESD-protected furniture, personnel and, finally, cleaning and maintenance with measurements. If possible, it is a good idea to optimize the EPA layout so that the movement of sensitive components from bench to bench is minimized. Then you are ready to work on any type of ESD sensitive components without any problems. No matter whether you are a component producer, electronics manufacturer or only occasionally work on sensitive electronic components, it is important to have ESD protection in place. Investing in ESD protection usually pays back in terms of both money and brand.If your products are long lasting and reliable they are usually also appreciated by your customer.
10 TRESTON | ESD WORKSPACES All the steel parts are light grey RAL 7035 and have a semiconductive paint film. The semi-conductive powder coating we use is based on epoxy and polyester resin, which at elevated temperatures melts, cures and forms a semiconductive paint film. This powder coating is developed especially for the ESD-protected areas (EPA). In addition, the paint film has excellent mechanical properties, i.e. abrasion and impact resistance and elasticity. It is not scratched easily and withstands action by chemicals, greases and solvents. The products with colour code 49 (RAL 7035) are entirely ESD-protected: all the steel parts have a semi-conductive Colour codes The colour code is included in those product codes that are formed with numbers. It is either at the end, following the hyphen (e.g. 860 804-49), or in the middle (e.g. C 334 49 000). paint film, castors, mats and bench tops are all made of semi-conductive materials. Please note that the semiconductive powder coating RAL 7035 has a slightly darker shade of colour that the given RAL code. !
Certificate of Qualification Q873/2024 V1.1 10.3.2024 Toni Viheriäkoski Cascade metrology Oy, Hakulintie 32, 08500 Lohja toni.viheriakoski@cascademetrology.com 1/1 Certificate of Qualification ESD Control Items — Workstations — Treston Concept Ergo Electric Adjustable Concept Ergo Allen Key Adjustable ESD control characteristics of Treston Concept Ergo workstations were assessed in accordance with IEC 61340-5-1 and IEC 61340-2-3. Summary of the qualification is shown in Table 1. Detailed information of qualification tests is presented in a technical report C873/2024. Table 1: General Information Client Treston Oy, Sorakatu 1, 20730 Turku. Contact Jani Aaltonen, +358 50 477 6850, Jani.aaltonen@treston.com. Dates of Test 18.-23.2.2024 (C873/2024). Author Toni Viheriäkoski, Cascade metrology, Electrostatics laboratory, Hakulintie 32, 08500, Lohja. Place of Test Clean room, Hemmolankatu 19, No 33, 01850, Lohja. Conditioning 48 hours, RH = (12 ± 3) %, T = (23 ± 2) °C. Samples under Test Sample 1: Concept Ergo electric adjustable workstation. Sample 2: Concept Ergo allen key adjustable workstation. Test Equipment BMM2000ESD Sn /1387, HM41 Sn M1850876, Cylindrical electrodes Warmbier 850 Sn 4940, Sn 4925, Concentric ring electrode Prostat PRF-911 Sn 452. Test Method(s) IEC 61340-2-3:2016, Edition 2.0, Electrostatics – Part 2-3: Methods of test for determining resistance and resistivity of solid materials used to avoid electrostatic charge accumulation. Assessment Criteria IEC 61340-5-1:2016, Edition 2.0, Electrostatics – Part 5-1: Protection of electronic devices from electrostatic phenomena. Summary of Results The samples met the requirements of working surfaces according to IEC 61340-5-1. Resistances to groundable point and point to point resistances were below 1 × 109 Ω. Results and observations are presented in a technical report C873/2024. Note This certificate may only be reproduced in full, except with the prior written permission by issuing laboratory. The results relate only to the tested items. Date and place Author Lohja 10.3.2024 Toni Viheriäkoski, CEO, Cascade Metrology, ESD Engineer Certificate of Qualification Q516/2017 V1.1 16.3.2017 Toni Viheriäkoski Cascade metrology Oy, Hakulintie 32, 08500 Lohja toni.viheriakoski@cascademetrology.com 1/1 Certificate of Qualification ESD control items – Treston Chairs C15AL-ESD, C18PU-ESD, C19PU-ESD, C20PU-ESD, C25PU-ESD, C30AL-ESD, C30BL-ESD, C30B-ESD, C35AL-ESD, C35BL-ESD, C35B-ESD, C40AL-ESD, C40BL-ESD, C50BL-G-ESD, C50BL-O-ESD, Saddle G ESD, Saddle AL ESD ESD-control characteristics of the chairs were assessed in accordance with IEC 61340-5-1 and IEC 61340-2-3. Summary of the qualification is shown in Table 1. Detailed information is presented in technical reports C490/2016 and C516/2017. Table 1: General Information Client Treston Oy, Sorakatu 1, 20730 Turku Contact Kimmo Lehti, +358 50 395 8562, kimmo.lehti@treston.com Dates of Test November 14 – 28, 2016 (C490/2016), February 20 - March 3, 2017 ( C516/2017) Place of Test Cascade Metrology, Electrostatics Laboratory, Hakulintie 32, 08500 Lohja GSM +358 4456 88 599 Conditioning 48 hours, RH = (12 ± 3) %, T = (23 ± 2) °C Samples under Test C15AL-ESD, C18PU-ESD, C19PU-ESD, C20PU-ESD, C25PU-ESD, C30AL-ESD, C30BL-ESD, C30B-ESD, C35AL-ESD, C35BL-ESD, C35B-ESD, C40AL-ESD, C40BL-ESD, C50BL-G-ESD, C50BL-O-ESD, Saddle G ESD, Saddle AL ESD Test Equipment MIT415/2 Sn 101489531, BMM2000ESD Sn /1387, Ring electrode S11.11 Sn 452, HM34 Sn W1840018, 5 lbs IEC electrodes ETS, FMX 004 FX07501 Test Method(s) IEC 61340-2-3:2016, Edition 2.0, Electrostatics – Part 2-3: Methods of test for determining resistance and resistivity of solid materials used to avoid electrostatic charge accumulation Assessment Criteria IEC 61340-5-1:2016, Edition 2.0, Electrostatics – Part 5-1: Protection of electronic devices from electrostatic phenomena Summary of Results The samples met the resistance to groundable point requirements of seating according to IEC 61340 5 1. Resistance to groundable point was < 1 × 109 Ω. Note This certificate may only be reproduced in full, except with the prior written permission by issuing laboratory. The results relate only to the tested items. Date and place Author Lohja 16.3.2017 Toni Viheriäkoski, CEO, Cascade Metrology, ESD Engineer Certificate of Qualification Q514/2017 V1.1 15.3.2017 Toni Viheriäkoski Cascade metrology Oy, Hakulintie 32, 08500 Lohja toni.viheriakoski@cascademetrology.com 1/1 Certificate of Qualification Cleanroom Suitability of Treston Concept and WB Workstations The cleanroom suitability of Treston Concept and WB workstations was assessed in the cleanroom of ISO 14644-1 class 7, February 2017. The requirements of ISO class 7 were met at rest and in operation. Summary of the qualification is shown in Table 1. Detailed information is presented in a technical report C514/2017. Table 1: General Information Client Treston Oy, Sorakatu 1, 20730 Turku Contact Kimmo Lehti, +358 50 395 8562, kimmo.lehti@treston.com Dates of Test February 9 – 16, 2017 Place of Test Cascade Metrology, Electrostatics Laboratory, Hakulintie 32, 08500 Lohja GSM +358 4456 88 599 Conditioning ISO Class 7, RH = (25 ± 5) %, T = (23 ± 3) °C Samples under Test Sample 1: Concept motorized ESD workstation 10349015P+TT10060-ESD with accessories, SN 5219, 01/2017 Sample 2: WB811 EL ESD motorized workstation with accessories SN 7154, 01/2017 Test Equipment Particle counter Climet Cl 500 SN 956475, Temperature and humidity meter Vaisala HM 41 SN M1850876, Sensor Vaisala HMP 113 SN M1750872 Assessment Criteria EN ISO 14644-1:2015 Cleanrooms and associated controlled environments - Part 1: Classification of air cleanliness by particle concentration Summary of Results Requirements of ISO class 7 were met at rest and in operation. The requirements of ISO class 6 were also met at rest with the large particle sizes > 0.5 µm. Note This certificate may only be reproduced in full, except with the prior written permission by issuing laboratory. The results relate only to the tested items. Date and place Author Lohja 15.3.2017 Toni Viheriäkoski, CEO, Cascade Metrology, ESD Engineer Place and date: For the issuing office: Espoo, 15 November 2023 DNV - Business Assurance Keilaranta 1, 02150 Espoo, Finland Kimmo Haarala Management Representative Lack of fulfilment of conditions as set out in the Certification Agreement may render this Certificate invalid. ACCREDITED UNIT: DNV Business Assurance Finland Oy Ab, Keilaranta 1, 02150 Espoo, Finland - TEL: +358 10 292 4200. www.dnv.fi/assurance MANAGEMENT SYSTEM CERTIFICATE Certificate no.: C597451 Initial certification date: 15 November 2023 Valid: 15 November 2023 – 14 November 2026 This is to certify that the management system of Treston Oy Sorakatu 1, 20730 Turku, Finland and the sites as mentioned in the appendix accompanying this certificate has been found to conform to the Quality Management System standard: ISO 9001:2015 This certificate is valid for the following scope: Design, production, sales and marketing of workstations and material handling systems for industry and other technical environments and storage systems. Place and date: For the issuing office: Espoo, 15 November 2023 DNV - Business Assurance Keilaranta 1, 02150 Espoo, Finland Kimmo Haarala Management Representative Lack of fulfilment of conditions as set out in the Certification Agreement may render this Certificate invalid. ACCREDITED UNIT: DNV Business Assurance Finland Oy Ab, Keilaranta 1, 02150 Espoo, Finland - TEL: +358 10 292 4200. www.dnv.fi/assurance MANAGEMENT SYSTEM CERTIFICATE Certificate no.: C597452 Initial certification date: 15 November 2023 Valid: 15 November 2023 – 14 November 2026 This is to certify that the management system of Treston Oy Sorakatu 1, 20730 Turku, Finland and the sites as mentioned in the appendix accompanying this certificate has been found to conform to the Environmental Management System standard: ISO 14001:2015 This certificate is valid for the following scope: Design, production, sales and marketing of workstations and material handling systems for industry and other technical environments and storage systems. Certificate of Qualification Q872/2024 V1.1 10.3.2024 Toni Viheriäkoski Cascade metrology Oy, Hakulintie 32, 08500 Lohja toni.viheriakoski@cascademetrology.com 1/1 Certificate of Qualification Cleanroom Suitability of ESD Control Items Workstation — Treston Concept Ergo Electric Adjustable The cleanroom suitability of Treston Concept Ergo Electric adjustable workstation was assessed in the cleanroom of ISO 14644-1 class 7, February 2024. The requirements of ISO class 7 were met at rest and in operation. Summary of the qualification is shown in Table 1. Detailed information is presented in a technical report C872/2024. Table 1: General Information. Client Treston Oy, Sorakatu 1, 20730 Turku. Contact Jani Aaltonen, +358 50 477 6850, Jani.aaltonen@treston.com. Dates of Test 18.-23.2.2024 (C872/2024). Author Toni Viheriäkoski, Cascade metrology, Electrostatics laboratory, Hakulintie 32, 08500, Lohja. Place of Test Clean room, Hemmolankatu 19, No 33, 01850, Lohja. Conditioning ISO Class 7, RH = (30 ± 3) %, T = (20 ± 2) °C. Samples under Test Sample 1: Concept Ergo electric adjustable ESD workstation. Test Equipment Particle counter Climet Cl 500 SN 956475, Temperature-humidity meter Vaisala HM 41 SN M1850876, Sensor Vaisala HMP 113 SN M1750872. Assessment Criteria EN ISO 14644-1:2015 Cleanrooms and associated controlled environments - Part 1: Classification of air cleanliness by particle concentration. Summary of Results Requirements of ISO class 7 were met at rest and in operation. The requirements of ISO class 6 were also met at rest with the large particle sizes > 0.5 µm. Note This certificate may only be reproduced in full, except with the prior written permission by issuing laboratory. The results relate only to the tested items. Date and place Author Lohja 10.3.2024 Toni Viheriäkoski, CEO, Cascade Metrology, ESD Engineer 11 TRESTON | ESD WORKSPACES Our standards comply with the highest certification requirements Quality certification ISO 9001 : 2015 Environmental Management System certification ISO 14001 : 2015 Cleanroom suitability of Treston Concept Ergo and WB electric adjustable workstations ISO 14644-1 class 7 Cleanroom Suitability of Chair Treston Ergo C20PU-ESD ISO 14644-1, class 7 ESD certification Treston Concept Ergo, Concept, WB, QuatreX, TED, TP and TPH workstations, Multi Industrial and SAP trolleys, ESD bins fulfill the basic requirements of IEC 61340-5-1 ESD certification Treston Ergo, Treston Plus, Neon, Flex, Stools and saddle chairs fulfill the basic requirements of IEC 61340-5-1 To obtain a copy of our certificates, please contact info@treston.com. �10 YEARS� 10 YEAR GUARANTEE 10 YEAR GUARANTEE The guarantee period for Treston™ products is 10 years from the date of delivery with some exceptions. For plastic bins guarantee is 5 years. The warranty period for worksurfaces, electric components, saddle chairs, lights, and normal wear and tear items such as castors, slides and roll profiles is 2 years. For trading products and components as well as custom-made articles we guarantee 2-year warranty unless otherwise agreed. TRESTON WARRANTY PERIOD
300 kg 300 kg 500 kg 12 TRESTON | ESD WORKSPACES WB workbench, page 18 • Aesthetic, ergonomic and easily adaptable to a large variety of tasks and environments • Designed for the needs of R&D, electronics assembly and testing • Extensive range of accessories to meet any need. Various layout possibilities from back-toback to corner solutions • Maximum load capacity 300 kg Concept Ergo workbench, page 14 • Multiple bench variations with advanced ergonomic features • Perfectly suitable for assembly, quality control or packing environments • Highly adaptable to various applications and to the needs of the user • Superior range of accessories, easily reconfigured • Excellent stability, suitable for heavy loads up to 500 kg Workbenches Treston QuatreX workbench, page 20 • Electrical workbench specifically designed to offer supreme stability, flexibility, and precision • Meets the needs of various industries and segments, including luxury goods manufacturing, electronics manufacturing, fine mechanics, logistics, and maintenance • Flexibility and versatility – choose perforated or aluminium uprights • Maximum load capacity 300 kg
300 kg 200 kg 100 kg 300 kg 13 TRESTON | ESD WORKSPACES TED electric desk, page 22 • TED Electric Desk comes with quick, silent and wide height adjustment • This ergonomic sit-stand desk perfectly suits light-duty assembly work, packing applications, R&D and industrial offices • The desk can be customized with accessories which further enhance ergonomics, free desk space and provide order • The table withstands load of 200 kg TP workbench, page 24 • Standard and cost-effective workbench • Suitable for a wide range of tasks and environments • Superior range of accessories, easily reconfigured • Steel frame with loading capacity up to 300 kg TPH workbench, page 26 • Standard and cost-effective workbench with one shelf • Suitable for a wide range of tasks and environments • Essential range of accessories for basic needs • Steel frame with loading capacity up to 300 kg Quick Edge workstation, page 28 • The quickest height adjustment on the market - no electricity needed • Can be customised for various operating environments • Multiple accessories available: swivel arms for tool holders and screens, LED lights, shelves with dividers for cartons • Maximum load capacity 100 kg
1000, 1200, 1500, 1806, 2000 mm 600, 750, 900 mm 700-1100 mm 14 TRESTON | ESD WORKSPACES • Select the bench frame and the height adjustment method: allen key or electric. • Select a bench top to suit the frame. Concept Ergo - the most versatile workbench WORKBENCHES Concept Ergo ESD bench top • Light grey laminate surface • Grey edging • Thickness 25 mm • Semi-conductive (ESD) Concept Ergo bench frames Bench frame size W x D mm Code ESD Allen key adjustable Code ESD electric adjustable 1000 x 600 CE10060-49 CE10060EL-49 1000 x 750 CE10075-49 CE10075EL-49 1000 x 900 CE10090-49 CE10090EL-49 1200 x 600 CE12060-49 CE12060EL-49 1200 x 750 CE12075-49 CE12075EL-49 1200 x 900 CE12090-49 CE12090EL-49 1500 x 600 CE15060-49 CE15060EL-49 1500 x 750 CE15075-49 CE15075EL-49 1500 x 900 CE15090-49 CE15090EL-49 1800 x 600 CE18060-49 CE18060EL-49 1800 x 750 CE18075-49 CE18075EL-49 1800 x 900 CE18090-49 CE18090EL-49 2000 x 600 CE20060-49 CE20060EL-49 2000 x 750 CE20075-49 CE20075EL-49 2000 x 900 CE20090-49 CE20090EL-49 Bench height adjustment 700-1100 mm 700-1100 mm* Bench frame max load 500 kg 400 kg *Height adjustment speed 13 mm/ second. Concept Ergo bench tops Bench top size W x D mm Code ESD 1000 x 600 TT10060-ESD 1000 x 750 TT10075-ESD 1030 x 750 TT10375-ESD 1000 x 900 TT10090-ESD 1030 x 900 TT10390-ESD 1200 x 600 TT12060-ESD 1200 x 750 TT12075-ESD 1230 x 750 TT12375-ESD 1200 x 900 TT12090-ESD 1230 x 900 TT12390-ESD 1500 x 600 TT15060-ESD 1500 x 750 TT15075-ESD 1530 x 750 TT15375-ESD 1500 x 900 TT15090-ESD 1530 x 900 TT15390-ESD 1806 x 600 TT18060-ESD 1806 x 750 TT18075-ESD 1836 x 750 TT18375-ESD 1806 x 900 TT18090-ESD 1836 x 900 TT18390-ESD 2000 x 600 TT20060-ESD 2000 x 750 TT20075-ESD 2030 x 750 TT20375-ESD 2000 x 900 TT20090-ESD 2030 x 900 TT20390-ESD + Accessories from page 29 Superior range of accessories available for ergonomic Concept Ergo workstation. The Concept Ergo bench can be equipped with castors! Castor set Ø100 ESD, code LCS100CE-ESD Load capacity with castors 300 kg. Always adjust the bench with castors to the lowest position when the bench is moved.
15 TRESTON | ESD WORKSPACES Qty Name Size mm Code ESD 1 Concept Ergo allen key adjustable workbench frame 1500 x 750 CE15075-49 1 ESD bench top 1530 x 750 TT15375-ESD 1 Upright tube module, 1359 mm 2 x M750 UTM2X750M-49 1 Light and balancer rail 2xM750 1500 91849006P 1 Treston NaturLite LED 1200 TNL1200 2 Perforated panel M750 M750 x1003 861514-49 1 Steel shelf M750 740 x 300 836028-49 1 Steel shelf M750 740 x 400 852770-49 1 Aluminium bin rail M750 736 x 55 x 75 BP750C 1 Laptop/printer shelf 365 x 365 93049001P 1 Curved bin rail with arm 770 x 54 92949002P 1 Extension for curved bin rail with arm 770 x 54 860911-49 1 Magnifying lamp Wave LED ESD TWL ESD 1 Drawer unit 45/14-1 60349001 1 Drawer unit fastening set for Concept Ergo DFCE-49 1 Earthing box J6603 Concept Ergo ESD workstation 1 Concept Ergo workbench examples WORKBENCHES Concept Ergo Qty Name Size mm Code ESD 1 Concept Ergo electric adjustable workbench frame 1500 x 750 CE15075EL-49 1 ESD bench top 1530 x 750 TT15375-ESD 1 Upright tube module, 1359 mm 2 x M750 UTM2X750M-49 1 Light and balancer rail 2xM750 1500 91849006P 1 Treston NaturLite LED 1200 TNL1200 1 Perforated panel M750 718 x 389 861511-49 1 Perforated panel M750 718 x 1003 861514-49 1 Document holder A4 290 x 330 92849008P 1 Adjustable shelf M750 720 x 505 92049005P 1 Rotating tool panel frame, height-adjustable arm 513 x 320 860864-49P 1 Perforated panel M500 470 x 300 860951-49 1 Tool trough M500 470 x 150 860952-49 1 Bin rail M750 742 x 100 859151-49 Qty Name Size mm Code ESD 1 Concept Ergo allen key adjustable workbench frame 1500 x 750 CE15075-49 1 ESD bench top 1530 x 750 TT15375-ESD 2 Upright tube, 1359 mm 1359 860024-49 1 Tiltable top shelf TTS M750 1467 x 400 TTSM15004-49 1 Light and balancer rail 2 x M750 1500 91849006P 1 Treston NaturLite LED 1200 TNL1200 1 Perforated panel M1500 1474 x 389 861526-49 1 Drawer unit 45/14-1 60349001 1 Drawer unit fastening set for Concept Ergo DFCE-49 Concept Ergo ESD workstation 2 Concept Ergo ESD workstation 3 Watch the feature showcase video
16 TRESTON | ESD WORKSPACES WORKBENCHES Concept Ergo All non ESD sertified accessories are EPA – compatible when their combination of the potential charge level and physical distance to the ESDS –related parts is managed by ESD standard IEC 61340-5-1 Spacer bar for Concept Ergo Allen key adjustable frames Name Code ESD Spacer bar for Concept Ergo Allen key 1000 SBCE1000-49 Spacer bar for Concept Ergo Allen key 1200 SBCE1200-49 Spacer bar for Concept Ergo Allen key 1500 SBCE1500-49 Spacer bar for Concept Ergo Allen key 1800 SBCE1800-49 Spacer bar for Concept Ergo Allen key 2000 SBCE2000-49 We recommend using a spacer bar for a Allen key adjustable frame with castors. The spacer bar is not suitable for any accessories. Depth adjustable accessory bar for Concept Ergo Name Code ESD Depth adjustable accessory bar Concept Ergo 1000 DBCE1000-49 Depth adjustable accessory bar Concept Ergo 1200 DBCE1200-49 Depth adjustable accessory bar Concept Ergo 1500 DBCE1500-49 Depth adjustable accessory bar Concept Ergo 1800 DBCE1800-49 Depth adjustable accessory bar Concept Ergo 2000 DBCE2000-49 Depth adjustable accessory bars are used with footrests 860136-49 and 860196-49. Six adjustment holes in 50 mm steps. In 750/900 mm deep benches, the nearest hole is 415 mm from the front edge of the bench top. Lower shelf for Concept Ergo Name Size W x D mm Max load kg Code ESD Lower shelf for Concept Ergo 1000 828 x 600 60 LSCE1000-49 Lower shelf for Concept Ergo 1200 1028 x 600 60 LSCE1200-49 Lower shelf for Concept Ergo 1500 1328 x 600 60 LSCE1500-49 Lower shelf for Concept Ergo 1800 1634 x 600 60 LSCE1800-49 Lower shelf for Concept Ergo 2000 1828 x 600 60 LSCE2000-49 This steplessly height-adjustable shelf offers reliable support for tools, components, or storage bins. Supplied complete with shelf and brackets. Transport skate Name Max load kg Code ESD Transport skate 180 854 061-49 With a transport skate, one person can easily move benches. For longdistance moving, you will need two transport skates Compatible with tables with a max depth of 750 mm. Footrest, bar Name Size W x D mm Height mm Tilting Code ESD Footrest, bar 550 x 350 90-280 5-30° 860 136-49 Footrest, bar, with gas action 550 x 350 90-260 5-30° 860 196-49 Used with depth adjustable accessory bar for Concept Ergo. Footrest, bar Footrest, bar, with gas action Battery set Name Code Battery set BSC001 Suitable for Concept Ergo electric adjustable frames, Treston QuatreX and TED electric desks. Battery set sold only to EU countries. Note: Battery set is not ESD certified. !
1000, 1200, 1500, 1800 mm 600, 750, 900 mm 675-1025 mm TRESTON | ESD WORKSPACES WORKBENCHES Concept hand crank Concept hand crank workstation Concept hand crank adjustable workbench frame Size W x D mm Max load kg Code ESD 1000 x 600 1000 x 750 1000 x 900 200 200 200 101 49 015 101 49 030 101 49 062 1200 x 600 1200 x 750 1200 x 900 200 200 200 101 49 016 101 49 031 101 49 063 1500 x 600 1500 x 750 1500 x 900 200 200 200 101 49 017 101 49 032 101 49 064 1800 x 600 1800 x 750 1800 x 900 200 200 200 101 49 018 101 49 033 101 49 065 Bench height steplessly adjustable 675 - 1025 mm Concept bench tops Size W x D mm Code ESD 1000 x 600 TT10060-ESD 1000 x 750 TT10075-ESD 1000 x 900 TT10090-ESD 1030 x 750 TT10375-ESD 1030 x 900 TT10390-ESD 1200 x 600 TT12060-ESD 1200 x 750 TT12075-ESD 1200 x 900 TT12090-ESD 1230 x 750 TT12375-ESD 1230 x 900 TT12390-ESD 1500 x 600 TT15060-ESD 1500 x 750 TT15075-ESD 1500 x 900 TT15090-ESD 1530 x 750 TT15375-ESD 1530 x 900 TT15390-ESD 1806 x 600 TT18060-ESD 1806 x 750 TT18075-ESD 1806 x 900 TT18090-ESD 1836 x 750 TT18375-ESD 1836 x 900 TT18390-ESD ESD bench top • Light grey laminate surface • Grey edging • Thickness 25 mm • Semi-conductive (ESD) • Select the bench frame size. • Select a bench top to suit the frame. Depth adjustable accessory bar for Concept hand crank adjustable frame Suitabiilty Depth adjustment mm Code ESD Bench frame 1500 mm 150 860088-49 Bench frame 1800 mm 150 860089-49 The depth adjustable accessory bar can be used to fix a footrest or a CPU/ printer holder The Concept hand crank bench can be equipped with castors! Castor set Ø100 ESD, code 860429 -00 Load capacity with castors 300 kg. Always adjust the bench with castors to the lowest position when the bench is moved. + Accessories from page 29 Superior range of accessories available for ergonomic Concept hand crank workstation.
700-1100 mm 700-1100 mm 700-1100 mm 18 TRESTON | ESD WORKSPACES WB electric adjustable bench has a desk panel with memory function WB allen key adjustable bench Bench size W x D mm Max load kg Code ESD 1073 x 800 300 WB811 ESD 1500 x 800 300 WB815 ESD 1800 x 800 300 WB818 ESD We recommend using the cable tidy WBCT with WB Allen-key adjustable benches (page 42). WB electric adjustable bench Bench size W x D mm Max load kg Code ESD 1073 x 800 300 WB811 EL ESD 1500 x 800 300 WB 815 EL ESD 1800 x 800 300 WB818 EL ESD Height adjustment speed 20 mm/ second. Cable tidy as standard. WB crank adjustable bench Bench size W x D mm Max load kg Code ESD 1073 x 800 200 WB811 C ESD 1500 x 800 200 WB815 C ESD 1800 x 800 200 WB818 C ESD Cable tidy as standard. • Select the height adjustment method: allen key, electric or crank. • Stepless height adjustment between 700-1100 mm. WB - aesthetic and easily adaptable The WB bench can be equipped with castors! Castor set Ø100, Code ESD LCS100 ESD Load capacity with castors is the same as the bench loading capacity with adjustable screws. We recommend using the cable tidy WBCT with WB Allen-key adjustable benches. Always adjust the bench with castors to the lowest position when the bench is moved. WORKBENCHES WB ESD bench top • Light grey laminate surface • Grey edging • Thickness 25 mm • Semi-conductive (ESD)
+ TRESTON | ESD WORKSPACES WB workbench examples WB ESD workstation 2 Qty Name Size mm Code ESD 1 WB electric adjustable bench 1037 x 800 WB811 EL ESD 1 Castor set Ø 100 LCS100 ESD 1 Upright profile 1063 x 900 AL2X110W 1 LCD bracket MH 1 Bin profile 985 BP100 ESD 1 Auxiliary steel shelf A5 159 x 210 ASSA5 2 Treston NaturLite Led Wing 500 500 TNL500W WB ESD workstation 1 Qty Name Size mm Code ESD 1 WB workbench EL ESD 1500 x 800 WB815 EL ESD 1 Accessory frame 690 x 500 + 690 x 500 AKK150 1 Upright profile 1489 x 900 AL2X150W 1 Support bracket HSB150 1 Treston NaturLite LED 1200 TNL1200 1 Shelf 1500 x 310 ALH150 ESD 1 Perforated panel 668 x 500 ARL70 1 Bin profile 685 BP70 ESD WORKBENCHES WB Watch this animation showcasing the versatile usage options Qty Name Size mm Code ESD 1 WB electric adjustable bench 1800 x 800 WB818 EL ESD 1 Earthing box ESD J6603 1 Upright profile 1789 x 900 AL2X180W 1 Support bracket 1800 HSB180 1 Treston NaturLite Led 1200 TNL1200 1 Shelf 1800 x 310 ALH180 ESD 1 Accessory frame AKK ESD 690 x 500 + 990 x 500 AKK180 1 Perforated panel ESD 668 x 500 ARL70 2 Bin profile ESD 985 BP100 ESD 2 Auxiliary steel shelf A5 159 x 210 ASSA5 1 Swivel arm with tray 460 x 210 AKV400 ESD 1 LCD swivel arm MA 1 Magnifying lamp Wave LED ESD TWL ESD WB ESD workstation 3 Drawer units starting from page 70 Explore the drawer units compatible with the WB bench.
710 - 1210 mm 750, 900 mm 1025, 1225, 1525, 1825, 2025 mm + 20 TRESTON | ESD WORKSPACES • Select the bench frame and add ESD grounding set • Select a bench top to suit the frame ESD bench top • Light grey laminate surface • Grey edging • Thickness 25 mm • Semi-conductive (ESD) Treston QuatreX electric workbench Treston QuatreX bench frame Name Size W x D mm Max load kg Code Four-leg electric bench frame 1025 x 750 300 QX10375-41 Four-leg electric bench frame 1225 x 750 300 QX12375-41 Four-leg electric bench frame 1525 x 750 300 QX15375-41 Four-leg electric bench frame 1825 x 750 300 QX18375-41 Four-leg electric bench frame 2025 x 750 300 QX20375-41 Four-leg electric bench frame 1025 x 900 300 QX10390-41 Four-leg electric bench frame 1225 x 900 300 QX12390-41 Four-leg electric bench frame 1525 x 900 300 QX15390-41 Four-leg electric bench frame 1825 x 900 300 QX18390-41 Four-leg electric bench frame 2025 x 900 300 QX20390-41 ESD Grounding set for Treston QuatreX QX-ESD Height adjustment speed 36 mm / second Side plates Name Size mm Code Side plates for Treston QuatreX depth 750 SPQX750-49 Side plates for Treston QuatreX depth 900 SPQX900-49 The optional side plates, available as an accessory, ensure a safe environment when two tables are used side by side. Includes two plates, right hand and left hand versions. Treston QuatreX bench tops Size W x D mm Code ESD 1030 x 750 TT10375-ESD 1030 x 900 TT10390-ESD 1230 x 750 TT12375-ESD 1230 x 900 TT12390-ESD 1530 x 750 TT15375-ESD 1530 x 900 TT15390-ESD 1836 x 750 TT18375-ESD 1836 x 900 TT18390-ESD 2030 x 750 TT20375-ESD 2030 x 900 TT20390-ESD Battery set Name Code Battery set BSC001 Suitable for Concept motor adjustable frames, Treston QuatreX and TED electric desks. Battery set sold only to EU countries. Note: Battery set is not ESD sertified. WORKBENCHES Treston QuatreX The QuatreX bench can be equipped with castors! Castor set Ø100, code LCS100 ESD Load capacity with castors 300 kg. Always adjust the bench with castors to the lowest position when the bench is moved. Accessories from page 29 and 42 QuatreX is the first Treston workbench to utilize both upright tubes, and aluminium upright profiles, offering more flexibility in workstation setup.
TRESTON | ESD WORKSPACES WORKBENCHES Treston QuatreX Treston QuatreX workbench examples Qty Name Size mm Code ESD 1 QuatreX electric bench frame 1525 x 750 QX15375-41 1 ESD bench top 1530 x 750 TT15375-ESD 1 ESD grounding set QX-ESD 1 Upright profiles 1489 x 1200 AL2X150QX 1 Accessory frame AKK150 1 Support bracket 1500 HSB150 1 Shelf 1500 x 310 ALH150 ESD 1 Treston NaturLite Led Plus 1200 TNL1200P 2 Perforated panel 668 x 500 ARL70 1 Small-parts storage cabinet 310 x 180 x 290 291-4ESD 1 Bracket for fixing small plastic storage cabinet to perforated panel 890 535-51 1 LCD swivel arm MA 1 Power rail 683 TPR7-001 1 Swivel arm with tray 460 x 210 AKV400 ESD Qty Name Size mm Code ESD 1 QuatreX electric bench frame 1525 x 750 QX15375-41 1 ESD bench top 1530 x 750 TT15375-ESD 1 ESD grounding set QX-ESD 1 Upright tube module, 1359 mm 2 x M750 UTM2X750M-49 3 Steel shelf M750 x 300 836028-49 1 Perforated panel M750 x 612 861512-49 1 Power rail 683 TPR7-001 1 Light and balancer rail 2 x M750 91849006P 1 Drawer unit 45/14-1 450 x 520 x 140 60349001 1 Drawer unit 45 fastening set for Quatrex 855058-49 1 Treston NaturLite Led 1200 TNL1200 Qty Name Size mm Code ESD 1 QuatreX electric bench frame 1525 x 750 QX12375-41 1 ESD bench top 1530 x 750 TT12375-ESD 1 ESD grounding set QX-ESD 1 Upright profiles 1489 x 1200 AL2X110QX 1 Support bracket 1500 HSB110 1 Shelf 1500 x 310 ALH150 ESD 1 Treston NaturLite Led Plus 1200 TLN900 1 Bin profile 985 BP100 ESD Treston QuatreX ESD workstation 1 Treston QuatreX ESD workstation 3 Treston QuatreX ESD workstation 2 Watch the feature showcase video
900/1100/1500/1800 mm 800 mm 630 -1270 mm 22 TRESTON | ESD WORKSPACES WORKBENCHES TED TED desk can be equipped with castors! Castor set Ø100 ESD Code LCS100 ESD Always adjust the bench with castors to the lowest position when the bench is moved. TED - electric desk for industrial use • TED desk consists of the frame and the bench top. • Quick, silent and wide height adjustment 630-1270 mm (range 64 cm) Upright Tube Pair with a flange Size W x D x H mm Code ESD 70 x 100 x 418 TTP400-49 70 x 100 x 793 TTP790-49 70 x 100 x 997 TTP990-49 Treston upright tubes enable TED electric desk to be accessorised in many ways. Fitted on worktop with screws. TED Electric Desk Bench size W x D mm Module Max load kg Code ESD 900 x 800 M750 200 TED809-49 1100 x 800 M900 200 TED811-49 1500 x 800 M1350 200 TED815-49 1800 x 800 M1500 200 TED818-49 Height adjustment speed 22 mm / second Lower shelf for TED desk Size W x D mm Suitable for Max load kg Code ESD 465 x 400 All TED benches 60 LST500-49 715 x 400 TED811, TED,815, TED818 60 LST750-49 865 x 400 TED815, TED818 60 LST900-49 965 x 400 TED815, TED818 60 LST1000-49 1165 x 400 TED818 60 LST1200-49 1315 x 400 TED818 60 LST1350-49 Divider hoops set (4 pcs) 400 x 400 PDH400-49 Includes back lip. Fitted under worktop with screws. The lower shelf can also be equipped with divider hoops. ESD bench top • Light grey laminate surface • Grey edging • Thickness 25 mm • Semi-conductive (ESD)
TRESTON | ESD WORKSPACES Watch the 2 min animation showcasing the features WORKBENCHES TED TED desk examples TED ESD workstation 2 Qty Name Size mm Code ESD 1 Treston Electric Desk 1100 x 800 TED811-49 1 Upright Tube Pair with a flange 790 TTP790-49 1 Perforated back panel M900 861 516-49 1 LCD monitor holder for perforated panel 890 715-49 2 Treston NaturLite Led Wing 500 TNL500W 2 Auxiliary steel shelf for perforated panel 159 x 210 ASSA5PP 1 Bottle holder ESD for upright tube Ø100 859 063-49 1 Laptop/printer shelf ESD 365 x 365 930 49 001P 1 Cable clip set for upright tubes CC5 1 Power rail 836 TPR9-010 TED ESD workstation 3 Qty Name Size mm Code ESD 1 Treston Electric Desk ESD 1500 x 800 TED815-49 1 Upright Tube Pair with a flange 790 TTP790-49 1 Light and balancer rail ESD 918 49 011P 1 Treston IntoLite Led 850 TIL850 1 Perforated back panel M1350 861 521-49 1 Treston Display Bracket for light duty TDB-49 1 Curved bin rail ESD with arm 770 x 54 929 49 002P 1 Steel shelf ESD M1350 1340 x 300 860 787-49 1 Aluminium bin rail M1350 BP1350C 2 Auxiliary steel shelf 159 x 210 ASSA5 1 Magnifying lamp Wave LED ESD TWL ESD 1 Drawer unit ESD 30/15 859 330-49 1 Drawer unit 30 fastening set for TED 855 057-49 1 Power rail 836 TPR9-010 TED ESD workstation 1 Qty Name Size mm Code ESD 1 Treston Electric Desk 1500 x 800 TED815-49 1 Upright Tube Pair with a flange 400 TTP400-49 2 Treston Display Bracket for light duty TDB-49 1 Drawer unit ESD 30/22 859 340-49 1 Drawer unit 30 fastening set for TED 855 057-49 1 Bottle holder ESD for upright tube Ø100 859 063-49
650-900 mm 500 / 700 / 900 mm 700 / 1000 / 1200/ 1500 / 1800 mm 24 TRESTON | ESD WORKSPACES The TP bench can be equipped with castors! Castor set Ø100, code ESD 860 429 -00. Insert set (required to fit castors), code 853 289-00 Load capacity with castors 150 kg. We recommend using the fixing frame for the castors. Always adjust the bench with castors to the lowest position when the bench is moved. • Stepless height adjustment with allen key between 650-900 mm. • Upright tubes (ordered separately) allow to attach a wide range of accessories. TP workbench Bench size W x D mm Max load kg Code ESD 700 x 500 150 TP507 ESD 1000 x 500 150 TP510 ESD 1500 x 500 150 TP515 ESD 1000 x 700 300 TP710 ESD 1200 x 700 300 TP712 ESD 1500 x 700 300 TP715 ESD 1800 x 700 300 TP718 ESD 1500 x 900 300 TP915 ESD 1800 x 900 300 TP918 ESD TP - ideal basic workbench ESD bench top • Light grey laminate surface • Grey edging • Thickness 25 mm • Semi-conductive (ESD) Lower steel shelf LSS Name Size W x D mm Max load kg Code ESD Lower shelf 1418 x 460 30 LSS150 Lower shelf 1718 x 460 30 LSS180 Low M-divider hoops (4 pcs/set) 460 x 315 LDH Hangs on the horizontal bars. Can be equipped with steplessly adjustable low M-divider hoops. WORKBENCHES TP TP extension benches also available! For more information please check our web site www.treston.com or Main catalogue page 49.
25 TRESTON | ESD WORKSPACES TP workbench examples TP ESD workbench 1 Qty Name Size mm Code ESD 1 Workbench TP 1500 x 700 TP715 ESD 1 Accessory frame 1500 TPK15-49 1 Upright tube module 2 x M750 UTM2X750M-49 TP ESD workbench 2 Qty Name Size mm Code ESD 1 Workbench TP 1500 x 700 TP715 ESD 1 Accessory frame 1500 TPK15-49 1 Upright tube module 2 x M750 UTM2X750M-49 1 Light/balancer rail 2 x M750 918 49 006P 1 Treston NaturLite LED1200 1180 TNL1200 2 Steel shelf M750 x 300 836 028-49 2 Bin profile M750 859 151-49 10 Stacking bin 1525-4ESD WORKBENCHES TP Watch this animation showcasing the versatile usage options TP ESD workbench 3 Qty Name Size mm Code ESD 1 TP workbench 1200 x 700 TP712 ESD 1 Accessory frame 1200 TPK12-49 1 Upright tube module 1 x M1200 UTM1X1200M-49 1 Tiltable top shelf M1200 x 300 TTSM12003-49 1 Light and balancer rail M1200 918 49 010P 1 Treston IntoLite Led 850 TIL850
1080-1550 mm 1200 / 1500 / 1800 mm 700 / 900 mm 310 mm TPH715* TPH715* TPH707 KK 26 TRESTON | ESD WORKSPACES ESD bench top • Light grey laminate surface • Grey edging • Thickness 25 mm • Semi-conductive (ESD) Workbench TPH Bench size W x D mm Shelf size W x D mm Max load kg Code ESD 1200 x 700 1200 x 310 300 TPH712 ESD 1500 x 700 1500 x 310 300 TPH715 ESD 1800 x 700 1800 x 310 300 TPH718 ESD 1500 x 900 1500 x 310 300 TPH915 ESD 1800 x 900 1800 x 310 300 TPH918 ESD Corner workbench TPH KK Bench size W x D mm Max load kg Code ESD 1100 x 1100 150 TPH707 KK ESD 1300 x 1300 150 TPH909 KK ESD A corner workbench can be used with two TPH benches (with one H-frame pair) to create a 90 °angle setup. TPH KK unit consists of a worktop, two H-frames and a leg in the middle. Front side 565 mm. TPH - standard workbench with one shelf • Stepless height adjustment with allen-key between 650-900 mm. • Includes a pair of uprights and one shelf Lower steel shelf LSS Name Size W x D mm Max load kg Code Lower shelf 1418 x 460 30 LSS150 Lower shelf 1718 x 460 30 LSS180 Low M-divider hoops (4 pcs/set) 460 x 315 LDH Hangs on the horizontal bars. Can be equipped with steplessly adjustable low M-divider hoops. WORKBENCHES TPH * Workbench with one H-frame pair.
27 TRESTON | ESD WORKSPACES TPH workbench examples TPH ESD workbench 2 Qty Name Size mm Code ESD 1 TPH workbench 1500 x 700 TPH715 ESD 1 Tool and lighting support 1500 x 600 KT150 1 Treston NaturLite LED 1200 TNL1200 TPH ESD workbench 3 Qty Name Size mm Code ESD 1 TPH workbench 1500 x 700 TPH715 ESD 1 Tool and lighting support 1500 x 600 KT150 1 Treston NaturLite LED 1200 TNL1200 1 Divider hoops set ESD, 5 pcs 400 PDH 1 Perforated panel 1415 x 750 RL150 1 Perforated panel connectors for TPH RK1 1 Swivel arm with tray 460 x 210 CKV400 ESD 1 Component rack 455 x 200 EPL12 ESD 12 Stacking bin, black ESD 105 x 165 x 75 1015-4ESD 1 Drawer unit 45, 1x100 450 x 520 x 140 603 49 001 TPH ESD workbench 1 Qty Name Size mm Code ESD 1 TPH workbench 1500 x 700 TPH715 ESD 1 Auxiliary shelf 1500 x 310 SH150 ESD 1 Light steel cabinet, 2 x100 370 x 460 x 245 LMC02 ESD WORKBENCHES TPH
M1200 700 mm 1930 mm 570 -1300 mm 28 TRESTON | ESD WORKSPACES Treston Quick Edge workstation - extremely fast height adjustment WORKBENCHES Quick Edge • Quick Edge workstation consists of the frame, the bench top and upright profiles. • Equip with M1200 wide accessories, swivel arms or printer platforms. • Quick Edge workstation can be used in EPAs with grounding set TQE-ESD. Quick Edge workstation Size W x D mm Module Max load kg Code 1200 x 700 M1200 100* TQEW712-41 Static load capacity for bench top 100 kg, total load capacity for frame 300 kg. Spring set for Treston Quick Edge Workstation Name Code Spring set for Treston Quick Edge Workstation TQES Replace the constant force spring set at least after every 10 000 operating cycles. Grounding set for Treston Quick Edge workstation Name Code ESD Grounding set for Treston Quick Edge workstation TQE-ESD With this grounding set you can use Treston Quick Edge workstation in EPAs. Quick Edge workstation can be equipped with castors. The new, innovative, patent pending height adjustment solution minimises the height exchange time between handled items and makes daily work more fluent, efficient, and ergonomic. Bench top is adjusted without load due to the constant force springs as an adjustment mechanism. Castor set ESD Ø 100 Code LCS100 ESD Grounding set for Treston Quick Edge workstation
29 TRESTON | ESD WORKSPACES ESD accessories for Concept Ergo, QuatreX, TED, Quick Edge and TP Our Concept Ergo, Concept, QuatreX, TED, Quick Edge, and TP benches can be fitted with the same accessories and they are interchangeable. Many accessories are also compatible with our trolleys and cabinets. Upright tubes are the basic element for accessorising our industrial furnishings. Accessories are attached to Concept Ergo, Concept, QuatreX, TED and TP benches with the aid of upright tubes or a complete, upright tube module. The complete upright tube module includes upright tubes, horizontal profile, and fixing plugs. For the Concept Ergo, Concept and QuatreX bench, the upright tubes are attached to the rear case of the bench with the fixing plates or screws that are delivered with the bench. With the TP bench, you also need an accessory frame TPK (page 30), which also includes the fixing plates for the upright tubes. For the TED bench, upright tube pair with a flange is fitted on worktop with screws. Horizontal profile Upright tube Fixing plug set h= l= The modular (M) size refers to the distance between two upright tubes from the middle of the tube. The modular size is used to find the appropriate accessories. Upright tubes Name Size W x D mm Length (l) mm Code ESD Upright tube 30 x 60 500 860 991-49 Upright tube 30 x 60 800 860 142-49 Upright tube 30 x 60 996 860 367-49 Upright tube 30 x 60 1359 860 024-49 Upright tube 30 x 60 1582 860 025-49 Horizontal profile M500 HPM500-49 Horizontal profile M750 HPM750-49 Horizontal profile M900 HPM900-49 Horizontal profile M1000 HPM1000-49 Horizontal profile M1200 HPM1200-49 Horizontal profile M1350 HPM1350-49 Horizontal profile M1500 HPM1500-49 Horizontal profile M1800 HPM1800-49 Horizontal profile M2000 HPM2000-49 Fixing plug set (2 pcs) FPSET Upright tube modules and compatibility Suitable for bench widths C = Concept Ergo & Concept, TP = TP, Q = QuatreX Code S l = 996 mm h = 683 mm* Code M l =1359 mm h =1046 mm* Code L l =1582 mm h =1269 mm* 1000 1200 1500 1800 2000 1 x M750 C C/TP C C C UTM1X750S-49 UTM1X750M-49 UTM1X750L-49 1 x M900 C/TP C/TP C C C UTM1X900S-49 UTM1X900M-49 UTM1X900L-49 1 x M1200 C/TP/Q - UTM1X1200M-49 - 1 x M1500 C/TP/Q C C - UTM1X1500M-49 - 1 x M1800 C/TP/Q C/Q - UTM1X1800M-49 - 2 x M500 C/Q C UTM2X500S-49 UTM2X500M-49 UTM2X500L-49 2 x M750 C/TP/Q C C UTM2X750S-49 UTM2X750M-49 UTM2X750L-49 2 x M900 C/TP/Q C/Q UTM2X900S-49 UTM2X900M-49 UTM2X900L-49 3 x M500 C/TP/Q C UTM3X500S-49 UTM3X500M-49 UTM3X500L-49 4 x M500 C/Q UTM4X500S-49 UTM4X500M-49 UTM4X500L-49 *h = module's height measured from bench's top surface. Load capacity 100 kg / module spacing. With QuatreX the total load capacity of the upright structure is 150 kg. Upright tube module includes upright tubes, horizontal profile, fixing plugs, and 5 pcs of cable clips for easy cable management.
